I have made a statement to send out to some of our customers.  Our invoices have a picture file in the top of the page.  I want to do the same thing for these statements.

The instructions are below:

For a Report, the image file must exist in the Application Image Path. Fill in the Label
text box with the path to the image file, relative to the Image Path. Example:
Label: MyCompanyLogos\logo_12.bmp
Then press the Add Element to Form button. After the Static Picture has been added,
it can be moved or resized.

I've done that but the picture does not load on the page. See attached file.

Application Property Manager

IMAGE PATH: C:\Sesame2\Pics\

Static Picture on Report :

Label: CompanyLogo.jpg

The "picture not loading" icon appears where the picture should be.

I try opening the image in a new tab and I get this message:

Your file couldn’t be accessed
It may have been moved, edited, or deleted.
ERR_FILE_NOT_FOUND

The image location appears as:

file:///C:/Sesame2/SesameReports/SesameReports/STATEMENT_img_CompanyLogo.jpg

The image does load up in my Sesame Reports folder as a separate file.

What am I doing wrong?

Hi Renator,

Before your post, I had used a sample file CompanyLogo.jpg. (Sesame Seasons Outdoor Supply Store) Once, I used your settings it appear on the report header.  The odd thing is that a renamed my original file as CompanyLogo.jpg.  Despite this, I'm still getting the original logo.

I did a search for the logos and rename my logo as the only one that appears as the sample one.  Once I print the report, the sample one overs it.

This is the Global Code

#include "sbasic_include.sbas"
ReportHTMLFilter("SesameReports\", "", 0)
ReportHTMLFilter("<IMG SRC=", "<IMG WIDTH=""500"" HEIGHT=""200"" SRC=", 2)

It kept giving me errors when I included [size=9][/size]

Hi Ray,

I just tried it; it didn't work.
Is there any other location the original file could be that causing this?  I search my Pics folder on my workstation and the server.

Application Properties - Image Path: Pics
Image file Label - CompanyLogo.jpg

I've attached the image the report is suppose to print.  It is in my Pics folder (C:\Sesame2\Pics)

If you are running Client/Server, the image used will be in the image path directory on the Server computer. It is transferred to the client system when the report is run.

-Ray

If you are running Client/Server, I assure you it's coming from the Server. That logo is not embedded in Sesame.

-Ray

I tried the C:\Sesame2\Pics.
This folder contains CompanyLogo.jpg (my header), but when the report still prints the Sample version of CompanyLogo.jpg .  I tried changing it to my original file name INVOICE-HEADER2.png, but nothing comes up.
Nothing worked using the Server address despite having the same folder.

The only thing I can figure is the report is actually looking for the images in a different folder.  I just don't know where.

Hi Renato,

I tried that but it didn't work.

If I resolve the issue, I'll let you know.
